Technical Specification

• • pH / mV Range : 0-14 pH / ±1999 mV
  • pH Resolution : 0.01 pH
  • pH Relative Accuracy : ±0.02 pH
  • Temperature Range : 0 to 100ºC
  • Temperature Compensation : Manual
  • Slope : 80-120 %
  • Calibration Check Facility : In-built with Instrument

• Calibration Error Indication : For 7.00 pH and 4.01 pH

• Short Link : Provided to diagnose the problem either with Instrument OR Electrode
• Display : 3½ Digit Large LED Display
• Push Button Switch : For maintenance free operation
• Power Supply : 230VAC ±10%, 50 Hz
• Dimensions:
  ● Net Dimension: 22 x 21 x 11 cm (L x W x H)
  ● Gross Dimension: 33 x 30 x 24 cm (L x W x H)
• Weight:
  ● Net Weight: 1.5 kg
  ● Gross Weight: 3.5 kg
