Product Details

Applications

• Basic Weighing
• Parts Counting
• Check Counting
• Percent Weighing
• Check Weighing
• Dynamic Weighing
• Totalization
• Formulation
• Differential
• Density Determination
• Peak Hold
• Pipette Adjustment
• SQC
• Fill Weight Variation
• Flow Rate Control

Display

• 7-inch TFT 16.7M Color Touch Screen with Glass Overlay

Operation

• AC Adapter Input: 100-240 VAC 0.5A 50-60 Hz
• AC Adapter Output: 12 VDC 1.5A

Communication

• USB Host (Type A) x 2
• USB Device (Type B) x 1
• USB Device (Type C) x 1
• Ethernet (RJ45) x 1
• RS232 x 1
• Optional Wi-Fi and Bluetooth Dongle

Construction

• Modular Design
• Metal Base and Housing
• SST 316 Weighing Pan
• Motorized Leveling
• 2 Touchless Sensors and Status Lights
• Automatic Doors with Anti-pinch Safety Protection
• Anti-static Glass Draftshield
• Built-in Ionizer
• Sample Spotlight (1 mg models)

Design Features

• Time Synchronization NTP
• Support for HID (Human Interface Device) connection to a computer without drivers
• 4-level User Management and Internal System Log Capacity of 100,000 Entries
• 3000 Application Sample Libraries
