Specifications
Specifications
| Model |
LMWB04 |
LMWB06 |
| Column |
2 rows 4 holes |
2 rows 6 holes |
| Make |
LABMAN |
| Temp. range |
RT+5~100°C |
| Temp. Resolution Ratio |
0.1°C |
| Temp. Accuracy |
±0.5°C |
| Temp. Uniformity |
±1°C |
| Water sink |
Stainless steel, surface electrolysis treatment |
| Outer shell |
Cold rolled steel plate, surface electrostatic powder spray |
| Heater |
Stainless steel U type heating tube |
| Temp. control mode |
PID |
| Timer |
0~999 min (with timing function) |
| Timing function |
Fixed temperature operation, timing function, auto stop |
| Program |
Optional: multi-selection program control |
| Additional function |
Deviation correction, menu key lock, power failure backup, power-off parameter memory, PID adjustable |
| Sensor |
Thermal resistor |
| Safety device |
Over-temperature alarm, short-circuit protection |
| Power rating |
800W |
1200W |
| Inner Chamber size (WxLxH)mm |
305x305x135 |
470x305x130 |
| Packing size (WxLxH) (mm) |
405x405x250 |
565x405x250 |
| Internal volume (approx.) |
12L |
18L |
| Cover aperture |
Ø120mm |
| Cover Rings per hole |
5 |
| Power Supply |
Adaptor, Using AC 220V, 50/60Hz |
| Weight |
6.5kg |
8kg |
Features
Features
- It adopts new design structure, which could avoid the leakage of steam.
- There are pointer type temperature controller and intellectual type temperature controller for selecting.
- The intellectual temperature controller has high lightness, digital display and key operating button, which is easy to operate. It has high precision on controlling the temperature.
- Thermostatic Water Baths uses evaporating, drying, concentrating and thermostatically heating.
- Widely adopted in medical and research units, factories, universities, chemical dyeing and petroleum.
